Operational Guide
Configure computer
3.Select Properties.
4.In the Properties window, select Use the following IP Address.
5.Set the IP Address to 192.168.1.30 and the subnet Mask to 255.255.255.0. Like below.
Configure the laser software
1. The first step here is that you need to install the LightBurn software.
1.Run the Lightburn Installer | 2. Install Lightburn | 3. Finish installing |
2.Open lightburn and set a connection.
3.Select Ruida, and then select Next.
4.Select Ethernet/UDP, and then select Next to continue the next step.
5.Enter the default IP address of the machine 192.168.1.100 to complete the network configuration of Lightburn.6.Name your laser and enter the work area, for X Series, the area is 600×300mm.
7.Select Rear Left as origin.
8.Then the connection is finished.
Start your project
The connection interface will display the laser status as 'Ready', and now you can start your project.
Note: The Ethernet connection is not Plug and Play and requires configuration to work. It also does not function with Lightburn's "Find My Laser" utility. The Laser also does not take an auto-assigned IP address from your DHCP server on your local Router. The Laser has a static IP that must be set up to match your network(Default is 192.168.1.100 with a Subnet Mask of 255.255.255.0).
